EN 10204 3.1 material certificate
Can be included when agreed in the order.
1/3Rivets （铆接系列）
Half-Hex Blind Rivet Nut
GB/T17880.2 · Carbon Steel
- Material
- Carbon Steel
- Finish
- Zinc Plated
MOQ: 5000–10000 pcs
Share
Available with the order
Order assurance
The supplier has confirmed that the options below can be agreed for this product. The exact scope is fixed in the quotation or order.Dimensional inspection report
Can be provided for the agreed inspection scope.
Bulk carton packing
Available subject to confirmed piece weight and shipping requirements.
Palletized shipment
Available when pallet size and handling requirements are confirmed.
Small boxes with outer cartons
Available when the box quantity and labels are agreed.
Buyer branding and labels
Available after artwork, label content, placement and the applicable minimum batch are agreed.
Available options
Material
Finish
6 sizes
| Model | D₃ | L | d0 min | d0 max | g min | MOQ | Quantity and inquiry |
|---|---|---|---|---|---|---|---|
| M4*11 | M4 | 11 | 4.9 | 5.1 | 1.5 | 10000 | |
| M5*13 | M5 | 13 | 5.9 | 6.1 | 1.5 | 10000 | |
| M6*15.5 | M6 | 15.5 | 6.9 | 7.1 | 1.5 | 10000 | |
| M8*17 | M8 | 17 | 8.9 | 9.1 | 1.5 | 5000 | |
| M10*19 | M10 | 19 | 10.9 | 11.1 | 2.0 | 5000 | |
| M12*22 | M12 | 22 | 12.9 | 13.1 | 2.0 | 5000 |
GB/T17880.2 | M4*11
ModelM4*11
D₃M4
L11
d0 min4.9
d0 max5.1
g min1.5
MOQ10000
GB/T17880.2 | M5*13
ModelM5*13
D₃M5
L13
d0 min5.9
d0 max6.1
g min1.5
MOQ10000
GB/T17880.2 | M6*15.5
ModelM6*15.5
D₃M6
L15.5
d0 min6.9
d0 max7.1
g min1.5
MOQ10000
GB/T17880.2 | M8*17
ModelM8*17
D₃M8
L17
d0 min8.9
d0 max9.1
g min1.5
MOQ5000
GB/T17880.2 | M10*19
ModelM10*19
D₃M10
L19
d0 min10.9
d0 max11.1
g min2.0
MOQ5000
GB/T17880.2 | M12*22
ModelM12*22
D₃M12
L22
d0 min12.9
d0 max13.1
g min2.0
MOQ5000
Product description
Half-hex blind rivet nut with internal metric threads, manufactured from carbon steel with zinc plating. Supplied to GB/T17880.2. Available thread sizes M4 through M12 with body lengths from 11 mm to 22 mm. Mounting hole diameters and grip ranges are specified per size. Minimum order quantities are 10,000 pieces for M4–M6 and 5,000 pieces for M8–M12. For quotation, specify thread size, body length, and required quantity.
Key features
- Zinc plated finish
- Internal metric threads M4 to M12
- Half-hex body design
- Supplied to GB/T17880.2
Applications
- Automotive / Sheet Metal / Machinery / Electrical Equipment / Furniture / Solar & Energy Storage
Standard and order documents
The selected execution standard is the product basis. Published or order-specific documents are shown only when they have been confirmed for this product.
Frequently Asked Questions
What documented quality support is available for Half-Hex Blind Rivet Nut?
Documents: EN 10204 3.1 material certificate, Dimensional inspection report. Confirm the required scope and acceptance criteria in the quotation.
Which order and delivery details are already confirmed for Half-Hex Blind Rivet Nut?
MOQ: 5000–10000 pcs. Confirmed packing options include Bulk carton packing, Palletized shipment, Small boxes with outer cartons, Buyer branding and labels.
What information should be included in a quotation request for Half-Hex Blind Rivet Nut?
Provide the required standard, material, finish, quantity, delivery destination.
